Description
Features
Graphical user interface
A guided four step approach to achieve optimal weld parameters.
- The extremely intuitive LCD panel provides an overview of the settings and makes adjustment quick and efficient.
Optimised start sequence
For each Tungsten diameter.
- The start values are automatically set, ensuring smooth and accurate TIG starts every time.
Program memories
Store and recall 3 weld programs with direct access from the front panel or through trigger select.
- Deliver more productivity by eliminating the need to manually set the parameters
- Deliver consistent quality by welders of all skills
Trigger select
Allows the operator to recall stored program by tapping the torch trigger.
- Eliminating the need to walk back to the machine to change parameters.
Advanced Remote-control options
The weld current can be adjusted between or during welds.
- Compatible with Miller hand and foot controls (foot pedal).
- Select a wireless foot pedal for unrestricted flexibility
- Select a Miller EuroTorch with built in remote option in the handle.
Tack welding mode
Provide precise and repeatable tacks, ideal for when preparing the weld object.
- Store and recall directly from the front panel to save time between weld cycles
- Maintain control of the heat input
4TS trigger mode
For manual adjustment of the heat input from the torch trigger.
-
Toggle between two different current levels without extinguishing the arc
Optimized MMA performance
For Basic, Rutile and cellulosic electrodes.
- Select electrode type in the set-up menu to get suitable arc force and hot start parameters, ensuring good starts and good arc control
TIG Settings
- Adjustable Pre/Post gas
- Adjustable slope up/down
- Adjustable start/end current
- Dual weld current levels
- Pulse mode
- Tack mode
- Min/Max values for remotes
MMA/Stick settings
- Electrode selection
- Hot Start ™
- Arc force (DIG)
- Cellulosic mode
- Adjustable OCV (VRD)
- Min/Max values for remotes
